Main Specifications
Condition (used, new):
used and inspected
Type:
Front flange
Available Options
| Stock Place: | Availability: | Qty: |
| Ukraine | 1 pcs. |
  |
- Product overview
- Shipping & Payment
- Questions - Answers (0)
- Gearbox works better with (1)
- Overall height - 163 mm;
- Number of splines - 26 pcs.;
- The outer diameter of the splined part is 28.45 mm;
- Flange outer diameter - 94.05 mm;
- Number of mounting holes - 6 pcs.;
- The internal diameter of the mounting holes is 6.45 mm;
- The distance between the centers of the mounting holes is 37 mm;
