Planetary gear Mercedes-Benz CVT 722.8 A1693720205 A1693700343 - 3 satellites (16 teeth, outer Ø 25.40 mm), 90 teeth on ring gear

Planetary gear:

• Total height - 40 mm;
• Number of teeth on the outer gear ring - 36 pcs.;
• The outer diameter of the gear ring is 143.65 mm;
• Number of satellites - 4 pcs.;
• Number of teeth on the satellite - 16 pcs.;
• Satellite outer diameter - 25.40 mm;
• Inner diameter for sun gear - 85.20 mm;
• The inner diameter of the central hole is 63.10 mm;

Ring gear:

• Overall height - 18 mm;
• Number of teeth on the outer crown - 48 pcs.;
• Outside diameter of gear ring - 189.75 mm;
• Number of teeth on the helical gear - 90 pcs.;
