Main Specifications
Condition (used, new):
used, untested
Marking:
9B
Spare part number(s):
9L8P-7902-BG
Available Options
| Stock Place: | Availability: | Qty: |
| Ukraine | 5 pcs. |
  |
- Product overview
- Shipping & Payment
- Questions - Answers (0)
- Gearbox works better with (4)
- Overall height - 130 mm;
- Neck height - 52 mm;
- Outer neck diameter - 39.65 mm;
- Outer body diameter - 272.65 mm;
- Pilot height - 20 mm;
- Pilot outer diameter - 21 mm;
- Number of mounting studs - 4 pcs.;
- The total height of the mounting stud is 19 mm;
- The outer diameter of the mounting stud is 9.90 mm;
- The radius from the center of the pilot to the center of the mounting hole is 113 mm;
- Distance between centers of mounting holes - 159 mm;
