DODDE/CHRYSLER 62TE Oil Pump - Stator Height (Front 68 mm), RL052759AA R8052759AA

If the pump gears are worn, the oil pressure at idle speed drops so much that the automatic transmission goes into neutral.

Hub:

• Overall height - 147 mm;

Front side:

• Stator height (front side) - 68 mm;
• Number of splines - 27 pcs.;
• Outer diameter of splined part - 29.50 mm;

Outer body diameter - 146 mm;

Back side:

• Overall height - 65 mm;
• Number of sealing rings - 4 pcs.;
• Outer diameter over sealing rings - 51.50 mm;
• Outer diameter of the working part - 45.25 mm;

Oil pump:

Gear housing:

• Overall height - 46 mm;
• Outer diameter - 224.15 mm;
• Inner diameter of the sleeve - 38.20 mm;

Oil pump gears:


Pinion gear:

• Thickness - 14.60 mm;
• Inner diameter - 38 mm;
• Number of teeth - 12 pcs.;

Driven gear:

• Thickness - 14.60 mm;
• Outer diameter - 88 mm.;
• Number of teeth - 14 pcs.;

04531621, 04567869, 04567869AB, R4567869, R4567869AB

If the pump gears are worn out, the engine oil pressure at idle speed falls so that the automatic transmission shifts to neutral.

Chrysler 300/ 300M (2.7L, 3.5L), Concorde (2.7L, 3.2L, 3.3L, 3.5L), NewYorker (3.5L), Prowier (3.5L)

Dodge Intrepid (2.7L, 3.2L, 3.3L, 3.5L)

Tags: 04531621, 04567869, 04567869AB, R4567869, R4567869AB
